Aircraft Loading Configuration
The Boeing 747-400F (Freighter) is a versatile cargo aircraft designed for efficient and large-scale transport of goods. Understanding its loading configuration is crucial for maximizing payload, ensuring safety, and maintaining aircraft balance and structural integrity.
The following link provides more details on the loading configurations for each aircraft.
Select an aircraft to view its loading configuration sheet.
Main Deck |
30 x PMC (96″ X 125″) | |||
Lower Deck |
09 x PMC (96″ X 125″) | |||
ULD Combination are Permitted |
Yes | |||
Door Sizes |
Description | Inches | Centimeters | |
| Main deck side door | 134″ x 122″ | 340 x 310 cm | ||
| Main deck nose door | 105″ x 98″ | 266 x 248 cm | ||
| Forward hold | 110″ x 66″ | 279 x 167 cm | ||
| AFT hold | 103″ x 65″ | 279 x 167 cm | ||
| Bulk | 44″ x 46″ | 111 x 119 cm | ||
Cargo Tonnage |
ER-BAM : 113,000 Kgs / 640 CBM
ER-JAI : 111,500 Kgs / 640 CBM ER-BBJ : 114,000 Kgs / 650 CBM ER-BAJ : 112,500 Kgs / 640 CBM ER-BAG : 110,300 Kgs / 640 CBM |
|||
Maximum Permitted Height |
A1 , A2 , B1 , CLR to ELR 96″ | |||
| PL 113″ | ||||
| FLR to SLR 118″ | ||||
| X position 64″Inch | ||||
| Lower deck 64″Inch | ||||
Main Deck |
LD FWD |
Bulk |
||
Temperature Range |
4°C to 29°C | 4°C to 29°C | 4°C to 29°C | |
Ventilation |
Yes | Yes | Yes | |
Heating |
Yes | Yes | Yes | |
